Description
FEATURES:
• Spindle travels a full 3-1/8” with one revolution of the handle
• Large 12-1/2" x 17" precision ground work table features twin T-slot grooves and 4 table slots to accommodate any project
• One-handed belt tensioning allows for rapid speed changes
• Power switch features a safety key and large, paddle-style off button
• Integrated depth stop makes repetitive drilling quick and easy
• Xacta-X laser system easily identifies the drill center
• Long-lasting, built-in LED work light reduces shadows
• Table edge lip designed to make clamping easy
• Replaceable MDF table insert
• Large cast iron base provides stability
SPECIFICATIONS:
• Motor Power: 3/4 HP
• Number of Spindle Speeds: 16
• Motor Voltage: 115 V
• Spindle Speed Range: 210 - 3500 RPM
• Max Spindle Distance to Table: 18-5/16"
• Table Tilt (Deg.): -45 to 45
• Column Diameter: 2-3/4"
• Swing: 15"
• Chuck Size: 5/8"
• Spindle travels a full 3-1/8” with one revolution of the handle
• Large 12-1/2" x 17" precision ground work table features twin T-slot grooves and 4 table slots to accommodate any project
• One-handed belt tensioning allows for rapid speed changes
• Power switch features a safety key and large, paddle-style off button
• Integrated depth stop makes repetitive drilling quick and easy
• Xacta-X laser system easily identifies the drill center
• Long-lasting, built-in LED work light reduces shadows
• Table edge lip designed to make clamping easy
• Replaceable MDF table insert
• Large cast iron base provides stability
SPECIFICATIONS:
• Motor Power: 3/4 HP
• Number of Spindle Speeds: 16
• Motor Voltage: 115 V
• Spindle Speed Range: 210 - 3500 RPM
• Max Spindle Distance to Table: 18-5/16"
• Table Tilt (Deg.): -45 to 45
• Column Diameter: 2-3/4"
• Swing: 15"
• Chuck Size: 5/8"
