Description
Jet 723520K Features
- Sandsmart™ control continuously monitors the load on the drum motor and automatically regulates the speed of the conveyor motor to maintain the highest feed rate without overload
- Conveyor bed parallelism is easily adjusted by turning the dial on the outside of the bed - no tools required
- Parallelism adjust dial features a stop to quickly return the conveyor bed to a flat position
- Dust hood includes an integrated channel that mirrors the shape of the drum and directs chips and dust to the 4" collection port
- Dust hood includes an integrated channel that mirrors the shape of the drum and directs chips and dust to the 4" collection port
- Precision-machined and dynamically balanced extruded aluminum drum is designed to dissipate heat and protect the work surface from heat-damage
- Precision-flattened reinforced steel conveyor bed
- Redesigned conveyor system pulls the workpiece through the sander instead of pushing
- One rotation of the top-position handwheel adjusts the drum height by 1/16"
- The relative depth scale on the handwheel allows the user to reset and measure the depth for every project
- Infinitely variable speed control of up to 10 feet per minute allows the user to choose the optimal feed rate
- Toolless abrasive take-up clips make changing abrasives quick and easy
- Snipe is virtually eliminated thanks to the adjustable tension rollers that apply downward pressure to the workpiece
- Separate feed and drum motors provide independent control, optimizing the performance of the sander
- Conveyor belt TRACKERS™ reduce the need for manual belt adjustments
- Integrated on/off switch and variable speed control knob are conveniently located
- Stand features a 20" x 37" footprint to increase stability and has a storage shelf and pre-drilled holes for casters
- Drum is easily removable
- Drum utilizes sealed and permanently lubricated ball bearings for longer life
Jet 723520K Specifications
| Style (Type): | Open Stand |
| Drum Length (In.): | 16 |
| Drum Speed (RPM): | 1,720 |
| Drum Diameter (In.): | 5 |
| Drum Bearing Diameter (In.): | 1 |
| Conveyor Motor: | 43 in.-lbs. torque, direct drive, dc |
| Conveyor Speed (FPM): | 0 - 10 |
| Maximum Board Thickness (In.): | 3 |
| Maximum Board Width (In.): | 32 (two passes) |
| Minimum Board Length (In.): | 2-3/8 |
| Minimum Board Thickness (In.): | 1/32 |
| Dust Collection Minimum CFM Required (CFM): | 400 |
| Dust Port Outside Diameter (In.): | 4 |
| Motor Power (HP): | 1-1/2 |
| Motor Phase (PH): | 1 |
| Motor Voltage (V): | 115 only |
| Motor Amps: | 14 |
| Recommended Circuit Size (Amps.): | 20 |
